Low Frequency Power Inverter
Low Frequency Power Inverter
SM-Glass Series(2.2-3.2KVA)
Features:
- Pure sine wave inverter
- WIFI& GPRS available for IOS and android
- Buit-in 80A MPPT solar charge
- Buit-in anti-dusk kit for harsh environment (optional)
- Compatible with lithium-ion battery
- High PV input voltage range(90-450VDC)
- Smart battery charge design to optimize battery life
- Overload,high temperature,inverter output short circuit protection
- Cold restart function
| MODEL | SM-2200H | SM-3200H |
| Rated Power | 2200VA/1800W | 3200VA/3000W |
| INPUT | ||
| Voltage | 230VAC | |
| Selectable Voltage Range | 170-280VAC (for personal computers) 90-280VAC (for home appliances) | |
| Frequency Range | 50Hz/60Hz (Auto sensing) | |
| OUTPUT | ||
| AC Voltage Regulation (Batt. Mode) | 230VAC±5% | |
| Surge power | 4400VA | 6400VA |
| Transfer Time | 10ms (for personal computers) 20ms (for home appliances) | |
| Wave form | Pure Sine Wave | |
| BATTERY & AC CHARGER | ||
| Battery Voltage | 12VDC | 24VDC |
| Floating Charge Voltage | 13.5VDC | 27VDC |
| Over charge Protection | 15.5VDC | 31VDC |
| Maximum charge current | 60A | |
| SOLAR CHARGER | ||
| MAX. PV Array Power | 2000W | 3000W |
| MPPT Range@ Operating Voltage | 90-450VDC | |
| Maximum PV Array Open Circuit Voltage | 450VDC | |
| Maximum Charging Current | 80A | |
| Maximum Efficiency | 98% | |
| PHYSICAL | ||
| Dimension. D*W*H(mm) | 348*282*105mm | |
| Net Weight (kgs) | 5.0kg | 5.5kg |
| Communication Interface | RS232(Standard) GPRS/WIFI(Optional) | |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operating Temperature | -10℃ to 55℃ | |
| Storage Temperature | -15℃ to 60℃ | |
